What does my site need to run the Voldt® Sitecharge 2×11kW?
The Voldt® Sitecharge is built to slot into the supply
you already have. It runs on AC 220V ±15% or AC 380 V ±15% at 50 Hz, so
single-phase and three-phase sites are both covered without a special feed. The
5m output cable is included, while the input cable is selected by the
installer to suit local code and the 5-pin CEE socket on site.
The IP55 enclosure handles indoor or outdoor
placement, and the operating window of -30 °C to +55 °C means it stays in
service through Northern winters and Southern summers alike. Installation
altitude is rated up to 2,000 m, with operating noise below 30 dB, so it sits
comfortably near offices, residential blocks or workplace car parks.
For sites where a local screen isn't wanted, the
display is removable, which simplifies the install and reduces points of wear
in vandal-prone or tightly controlled environments.
