Toyota C-HR+ Charging cable

The Toyota C-HR+ is Toyota's all-electric coupé crossover, built on the e-TNGA platform and marking a sharp departure from the hybrid-only C-HR that preceded it. Three powertrain configurations span the range: a 57.7 kWh (approximately 54 kWh usable) front-wheel-drive variant producing 123 kW (167 hp) with a WLTP range of up to 458 km (285 miles), a 77 kWh (72 kWh usable) front-wheel-drive version delivering 165 kW (224 hp) and up to 607 km (378 miles), and a 77 kWh all-wheel-drive model with a combined 252 kW (343 hp) across dual motors, 0–100 km/h in 5.2 seconds, and a range of up to 548 km (341 miles). Top speed reaches 180 km/h on the 77 kWh variants. The standard onboard AC charger is rated at 11 kW across three phases, with a 22 kW three-phase charger fitted as standard on the High grade. DC fast charging peaks at 150 kW on all variants, with 10–80 % targeted at under 30 minutes. The CCS2 charging port sits on the left front flank.

AC wallbox charging: how long does the Toyota C-HR+ take?

With the standard 11 kW three-phase charger and a correctly rated Type 2 cable, the smaller 54 kWh usable battery charges from empty to full in approximately 5 hours and 25 minutes once typical efficiency losses of around 10 % are included. The larger 72 kWh pack takes around 7 hours and 10 minutes. Both sit well within an overnight window, and the smaller battery can also recover a full charge during a working afternoon.

High grade models equipped with the 22 kW charger cut the 77 kWh battery's charge time to approximately 3 hours and 35 minutes on a three-phase supply: a meaningful advantage for owners who need to charge and go within a shorter window.

On a single-phase 32 A home wallbox, the cable you choose determines how much power reaches the car. With a 22 kW cable (32 A per phase), the single available phase delivers 7.4 kW: the 54 kWh battery charges in approximately 8 hours, and the 72 kWh in around 10 hours and 40 minutes. An 11 kW cable restricts current to 16 A on that single phase, limiting the rate to 3.7 kW and roughly doubling the charge time. For any C-HR+ owner on a single-phase home supply, a 22 kW cable removes this bottleneck entirely.

DC rapid charging on the move

All C-HR+ variants support CCS2 DC rapid charging at up to 150 kW. Toyota targets a 10–80 % charge in under 30 minutes across both battery sizes, with the car's battery pre-conditioning system helping maintain these times even in temperatures as low as −10 °C. A full 0–100 % charge takes approximately 50 minutes for the 57.7 kWh battery and around 55–60 minutes for the 77 kWh, once the battery management system's end-of-charge taper is accounted for. On a longer journey, a single rapid stop covers comfortably over 200 km of additional range.

Choosing the right Type 2 cable for the Toyota C-HR+

A 22 kW Type 2 cable is the recommended choice for every C-HR+ owner, regardless of which charger is fitted.

With the standard 11 kW charger, an 11 kW cable delivers the full 11 kW at a three-phase wallbox. On a single-phase 32 A wallbox, however, the cable's 16 A per-phase rating restricts the charge to 3.7 kW. A 22 kW cable removes this bottleneck by allowing the full 32 A on the single available phase, bringing 7.4 kW to the car.

For High grade models with the 22 kW charger, a 22 kW cable is the only cable that delivers the charger's full capacity on a three-phase supply. An 11 kW cable would cap it at 11 kW, forfeiting half the available speed.

A 22 kW cable also future-proofs the purchase for any subsequent vehicle with 22 kW AC charging, and handles both single-phase and three-phase scenarios without compromise.

Cable length and parking

The C-HR+'s CCS2 port is positioned on the left front flank. Nose-in parking towards the wallbox places the port closest to the charger, keeping the cable route short and tidy.

Voldt® Type 2 cables are available in 4, 6, 8, 10, 15, 20, and 40 metre lengths. A 4 m cable suits a dedicated home setup where the wallbox sits directly beside the parking space. For most driveways and garages, 6 m provides comfortable reach. An 8 m cable is a versatile everyday option for both home and public charge points, while 10 m adds flexibility at public stations where the post may be further from the bay. A 15 m cable covers hotel car parks, wider bays, and longer driveways. The 20 m and 40 m lengths serve commercial, depot, and specialist installations.

Portable charging with a CEE charger

A Voldt® portable CEE charger extends the C-HR+'s charging options to any compatible industrial or domestic socket.

Connected to a 32 A or 16 A three-phase CEE socket (red, five-pin, found at industrial sites and workshops), the standard 11 kW charger draws its full ceiling. The 54 kWh battery charges in approximately 5 hours and 25 minutes; the 72 kWh in around 7 hours and 10 minutes.

At a blue 16 A single-phase CEE socket, the standard fixture at holiday campsites and caravan parks across Europe, output is limited to 3.7 kW. The 54 kWh battery takes around 16 hours for a full charge; the 72 kWh, roughly 21 hours and 25 minutes. The smaller battery can recover a full charge from a blue CEE socket within a single overnight-to-afternoon window; the larger one requires leaving the car connected continuously for the better part of a day. Red three-phase CEE sockets are not standard campsite infrastructure: they belong to industrial premises, workshops, and some commercial marinas.

From a standard European household socket (Schuko), continuous output is restricted to a safe 2.3 kW (10 A). The 54 kWh battery takes approximately 25 hours and 50 minutes; the 72 kWh, around 34 hours and 25 minutes. With batteries of this size, a domestic socket serves only as an emergency fallback and should not be relied upon for regular charging.

Built to last, backed by Voldt®

Voldt® charging cables are CE, UKCA and TÜV certified and manufactured according to IATF 16949 automotive quality standards. Single-piece moulded connectors, no glue or screws. IP67-rated for operation between −30°C and +50°C. 100% copper conductors with silver-plated contacts. Tested beyond 10,000 connection cycles. Three-year warranty, 100-day returns, free shipping across Europe.
