BMW 225XE charging cable

The BMW 225xe Active Tourer is one of the more distinctive plug-in hybrids in BMW's lineup, not only for its practical body style but for its drivetrain architecture. The 1.5-litre three-cylinder petrol engine drives the front wheels through a six-speed Steptronic gearbox, while a separate 65 kW electric motor mounted at the rear drives the rear axle independently, creating a hybrid-specific all-wheel drive system with no mechanical driveshaft connecting the two axles. Combined system output is 165 kW with 385 Nm of torque, and the 225xe reaches 100 km/h in 6.7 seconds. The electric motor's rear placement also means the battery sits beneath the rear seat without significantly intruding on boot space, a practical consideration in a family-oriented vehicle.

The 225xe was produced in the F45 generation from 2016 to 2022. Early cars carried a 7.6 kWh gross battery with around 5.8 kWh usable, while a 2019 update introduced a new cell generation that raised gross capacity to 10 kWh and usable capacity to 8.8 kWh within the same physical dimensions, extending WLTP electric range to between 50 and 53 km. Both generations use the same 3.7 kW single-phase onboard AC charger and the same left-front Type 2 charging port. No DC rapid charging is available on either. The F45 225xe was succeeded by the U06-generation 2 Series Active Tourer PHEV, which brought a larger battery and a higher charge rate. At 3.7 kW, the pre-2019 battery charges from empty in around two and a half hours at a wallbox. The post-2019 10 kWh battery takes approximately three and a quarter hours at the same rate. On a standard household socket at 2.3 kW, the larger battery takes around four to five hours, still a comfortable overnight charge.

Cable for the BMW 225xe

The 225xe uses a Type 2 connector across both generations, so a Voldt® Type 2 charging cable is the correct choice. The onboard charger is limited to 3.7 kW single-phase regardless of production year, so a 3.7 kW cable is the precise match. A 7.4 kW cable is worth specifying as an upgrade: it works identically at 3.7 kW on the 225xe and remains considerably more useful on any higher-capacity vehicle, either owned alongside or in future. An 11 kW or 22 kW cable adds a further step of versatility at modest extra cost and is sensible if you share the cable across multiple vehicles or charge regularly at three-phase public posts.

The left-front port position suits forward-entry bays naturally. Both generations of the 225xe charge their relatively small batteries quickly enough at 3.7 kW that cable reach is rarely a constraint. A 5 or 6-metre cable handles the majority of home setups without difficulty. An 8-metre cable is a practical default if you charge in varied locations, as it covers most public post configurations and wider parking spaces without requiring the car to be repositioned.

Portable charging for the BMW 225xe

The Voldt® portable CEE charging cable connects to industrial sockets and is available up to 22 kW via three-phase CEE. For the 225xe, a 16A single-phase CEE socket delivers around 3.7 kW: around two and a half hours for the original 5.8 kWh battery, and around three and a quarter hours for the 8.8 kWh battery, both well within any evening stop at a campsite, marina, or workshop. The Schuko portable charger delivers up to 2.3 kW from a standard household socket. For the smaller pre-2019 battery, that means a full charge from near-empty in approximately three hours. For the post-2019 8.8 kWh battery, around four to five hours, making the Schuko a practical overnight solution at any property with standard power rather than a backup of last resort.

Reliable from first charge to last

Voldt® charging cables are CE, UKCA and TÜV certified and manufactured according to IATF 16949 automotive quality standards. Single-piece moulded connectors, no glue or screws. IP67-rated for operation between −30°C and +50°C. 100% copper conductors with silver-plated contacts. Tested beyond 10,000 connection cycles. Three-year warranty, 100-day returns, free shipping across Europe.
