BMW 545E xDrive PHEV charging cable

The BMW 545e xDrive was the performance flagship of the G30 5 Series plug-in hybrid range, produced from 2021 to 2023. Where the four-cylinder 530e offered efficiency, the 545e delivered the full straight-six experience: a 3.0-litre B58 engine paired with an 80 kW electric motor through an eight-speed Steptronic gearbox and BMW xDrive all-wheel drive. Combined system output is 290 kW with 600 Nm of torque, reaching 62 mph in 4.6 seconds. In electric-only mode the car covers up to 35 miles in the WLTP cycle at speeds up to 87 mph, drawing on a 12 kWh battery (approximately 11.2 kWh usable) positioned under the rear seat. The onboard AC charger is rated at 3.7 kW single-phase (16A), filling the battery in approximately three and a half hours from a compatible wallbox. There is no DC rapid charging capability. The Type 2 charging port sits on the left front flank.

Cable match for the 545e xDrive

The 545e uses a Type 2 connector for AC charging, and a Voldt® 11 kW Type 2 charging cable is the correct match. The onboard charger draws 16A on a single phase, and an 11 kW cable supports exactly that amperage, delivering the car's full 3.7 kW from any wallbox or public post. There is no speed advantage from a higher-rated cable on this specific car, but a 22 kW cable works identically at 3.7 kW and is worth considering if you share the cable with a more capable vehicle or plan to keep it for a future car with a faster charger.

The charging port sits on the left front flank, so driving straight into a bay places the port closest to the charge point in most public layouts. With a battery of just 11.2 kWh, charging is quick enough that cable reach is rarely a concern, but getting the length right from the start still removes a small recurring inconvenience. A 6-metre cable covers most home wallbox setups comfortably. An 8-metre cable is the most practical all-round choice, handling most public post positions and home configurations without needing to reposition the car. A 10-metre cable adds reach at posts set further back from the bay, and a 15-metre cable handles hotel car parks, longer driveways, and wider commercial layouts without restriction.

Portable charging that keeps pace

The Voldt® blue CEE portable charger plugs into the single-phase 16A sockets found at campsites, marinas, and workshops across Europe, delivering 3.7 kW: the 545e's full onboard charging rate. At that speed the 11.2 kWh battery fills from near-empty in approximately three and a half hours, so a campsite overnight stop, a long lunch, or even a few hours at a marina delivers a complete charge. For a car with this battery size, the blue CEE portable is the most relevant industrial-socket option: a three-phase red CEE socket would deliver the same 3.7 kW (the car draws only one phase at 16A regardless of what the socket provides), so the single-phase blue CEE is the practical and honest choice.

Where only a standard domestic socket is available, the Voldt® three-pin portable charger draws up to 2.8 kW from a UK household socket, within the limits of what your wiring and installation can safely sustain. A built-in thermal sensor monitors the connection temperature continuously and adjusts the charging current automatically, so the charger adapts to the condition of the socket rather than assuming a fixed load. At that rate, a full charge from near-empty takes approximately four and a half hours. For a car designed to cover longer runs on the straight-six and shorter commutes on electricity, that is a comfortable overnight arrangement: plug in on arrival, and the battery is full well before any next departure. The three-pin charger turns any household socket into a daily charging point without needing a dedicated wallbox.

The standard behind every Voldt® cable

Every Voldt® charging cable is CE, UKCA and TÜV certified, built to automotive quality standards with single-piece moulded connectors, no glue, no screws. The housing carries an IP67 rating for full operation between −30 °C and +50 °C. Inside, 100% copper conductors with silver-plated contacts deliver minimal resistance and consistent performance across more than 10,000 tested connection cycles. Cables are available in 6, 8, 10, and 15-metre lengths, all backed by a three-year warranty, a 100-day return window, and free shipping across Europe.
