BMW X1 xDrive 25E PHEV charging cable

The BMW X1 xDrive25e has been offered across two generations, both sharing the same plug-in hybrid architecture: a 1.5-litre three-cylinder petrol engine driving the front wheels, an electric motor on the rear axle, and hybrid all-wheel drive without a mechanical link between the two. The F48 generation (2020–2022) pairs that engine with a 70 kW rear motor for a combined output of 162 kW, drawing from a 10 kWh battery (approximately 8.8 kWh usable). The onboard AC charger is rated at 3.7 kW single-phase (16A), filling the battery in approximately three hours from a compatible wallbox. The U11 generation (2023 onwards) steps up to an 81 kW rear motor and 183 kW combined, with a 16.3 kWh battery (approximately 14.2 kWh usable). The onboard charger doubles to 7.4 kW single-phase (32A), cutting full charge time to approximately two and a half hours. Neither generation supports DC rapid charging. The Type 2 charging port sits on the left front flank on both.

Which cable fits your X1 xDrive25e?

Both generations use a Type 2 connector, so a Voldt® Type 2 charging cable is the correct choice across the entire xDrive25e range. The right rating depends on which generation you have. For F48 owners, a Voldt® 11 kW Type 2 charging cable is the correct match: the onboard charger draws 16A on a single phase, and an 11 kW cable supports exactly that amperage, delivering the car's full 3.7 kW from any wallbox or public post. A 22 kW cable works identically at 3.7 kW and is worth considering if you share the cable with a more capable vehicle or plan to keep it for a future car.

For U11 owners, a Voldt® 22 kW Type 2 charging cable is the right choice. The onboard charger draws up to 32A on a single phase (7.4 kW), and only a 22 kW cable supports that amperage: an 11 kW cable, rated at 16A per phase, would halve the rate to 3.7 kW and roughly double the charge time. The 22 kW cable also works identically at 11 kW on any three-phase supply, making it the most versatile option to keep for any future vehicle.

The charging port sits on the left front flank on both generations, so driving straight into a bay places the port closest to the charge point in most public layouts. With batteries of 8.8 kWh and 14.2 kWh respectively, charging is quick enough that cable reach is rarely a concern, but getting the length right from the start still removes a small recurring inconvenience. A 6-metre cable covers most home wallbox setups. An 8-metre cable is the most practical all-round choice, handling most public post positions and home configurations without needing to reposition the car. A 10-metre cable adds reach at posts set further back from the bay, and a 15-metre cable handles hotel car parks, longer driveways, and wider commercial layouts without restriction.

Portable charging for every generation

For U11 owners, the Voldt® 22 kW portable charger connects to a 32A three-phase red commando socket, with the car drawing one phase at 32A for 7.4 kW: the U11's full onboard rate. At that speed the 14.2 kWh battery fills from near-empty in approximately two and a half hours, making any stop with a red CEE socket a practical full-charge opportunity.

The Voldt® blue CEE portable charger plugs into the single-phase 16A sockets found at campsites, marinas, and workshops across Europe, delivering 3.7 kW. For the F48, that fills the battery in approximately two and a half to three hours: the car's full onboard rate from a campsite socket. For the U11, approximately four to four and a half hours: comfortably within an overnight stop. For F48 owners specifically, the blue CEE portable is the most relevant industrial-socket option: a three-phase red CEE socket would deliver the same 3.7 kW (the F48 draws only one phase at 16A regardless of what the socket provides), so the single-phase blue CEE is the practical choice.

Where only a standard domestic socket is available, the Voldt® three-pin portable charger draws up to 2.8 kW from a UK household socket, within the limits of what your wiring and installation can safely sustain. A built-in thermal sensor monitors the connection temperature continuously and adjusts the charging current automatically, so the charger adapts to the condition of the socket rather than assuming a fixed load. For the F48, a full charge takes approximately three and a half to four hours. For the U11, approximately five and a half to six hours. Both sit comfortably within an overnight window, and for batteries of this size the three-pin charger is a practical daily solution rather than a fallback.

Trusted in every connection

Every Voldt® charging cable is CE, UKCA and TÜV certified, built to automotive quality standards with single-piece moulded connectors, no glue, no screws. The housing carries an IP67 rating for full operation between −30 °C and +50 °C. Inside, 100% copper conductors with silver-plated contacts deliver minimal resistance and consistent performance across more than 10,000 tested connection cycles. Cables are available in 6, 8, 10, and 15-metre lengths, all backed by a three-year warranty, a 100-day return window, and free shipping across Europe.
